Panasonic TX-55MZ800E OLED 4K GOOGLE TV

Picture Quality
Display
Panel
OLED 4K
Screen Resolution
3,840 (W) x 2,160 (H)
Panel Drive
Smooth Motion Drive PRO
Picture Mode
Dynamic/Normal/Cinema/TrueCinema/Filmmaker Mode/Sport/Game/DolbyVision
Muti HDR Support*²
HDR10+/HDR10/HLG/Dolby Vision
HDR Brightness Enhancer
Y
Dynamic HDR Effect
N
Contrast
Ultimate Contrast
Colour Space
Wide Colour Spectrum
Advanced Video Processor/Engine
4K Colour engine PRO
Local Dimming
N
Adaptive Backlight Dimming
N
Filmmaker Mode
Y
THX Certified Display*³
N
isf Mode
N
Sound Quality
Dolby Atmos
Y
Surround
N
Speaker Output
20 W (10 W x 2) + 12W woofer
Sound Mode
User, Standard, Vivid, Sport, Movie, Music, News
Dolby DAP: Game, Movie, Music, News, Stadium, Smart
Smart Features
Smart TV
Google TV
Voice Personal Assistant
Google Assistant Built-In
Voice Guidance
Y
EPG
Y
On Screen Display Menu Languages
35 Languages*¹⁶
Digital TV
DVB-T/T2/C/S/S2 - HEVC
Twin Tuner
—
Wireless LAN Built-in
Y
In-House TV Streaming (DVB-IP)
—
Panasonic TV Remote Apps
—
Swipe & Share
—
Web Browser*⁵
N
(Web Browser can be downloaded from Google Play Store)
Mirroring
Chromecast built in
Home Network*⁶
N
Bluetooth*⁷
Y
Bluetooth Audio Link*⁸
N
IP Home Control
N
Media Player
Y
Support Format
Video:.mpg/.mpeg/.dat/.vob/.mkv/.mp4/.m4v/.mov/.flv/.3gp/.3gpp/.ts/.trp/.tp/.rmvb/.rm/.avi/.265/.asf/.wmv/.webm/.ogm/.264/.avs/.vc1
Audio:.mp3/.avi/.asf/.wmv/.divx/.mkv/.mka/.3gpp/.3gp/.mp4/.mov/.m4a/.ts/.trp/.tp/.mts/.m2ts/.dat/.vob/.mpg/.mpeg/.flv/.wav/.ogm/.ac3/.ec3/.aac/.wav/.rm/.rmvb/.ra/.ogg/.dts/.flac/.webm/.ac4
Photo: .jpeg/.bmp/.png/.gif/.webP/.heif
Data Broadcasting
Hbb TV 2.0.3
Teletext Reception
1000P
USB-HDD Recording*⁹
Y
Multi Window
N
HDAVI Control
Y (CEC only)
Energy Data
Suppliers Trademark
Panasonic
Model ID
TX-55MZ800E
Energy Efficiency Class
G
Visible Screen Size (diagonal)
139 cm / 55 inches
On mode Average Power Consumption*¹⁰
82 kWh/1000h
Annual Energy Consumption*¹¹
—
Standby Power Consumption
0.5 W
Off mode Power Consumption
0.3 W
Screen Resolution
3,840 (W) x 2,160 (H)
Power Supply
AC 220 - 240 V, 50/60 Hz
Rated Power Consumption
-
Ambient Sensor (CATS)
N
Design
Switch Design
—
Terminal
Digital Tuner Reception
DVB-T/T2/C (side)
DVB-S/S2 (back)
Analogue Tuner
Y
HDMI*¹²
2 (side), 1 (back)
HDMI (4K 60/50p with HDCP2.3)
3
Support Feature
HDMI2.1
eARC (enhanced Audio Return Channel) (Input 2)
ALLM (Auto Low Latency Mode ) (All inputs)
USB
2 (2 side, USB 2.0 x 2) - USB Recording
Ethernet
1 (back)
CI (Common Interface)
1 (CI Plus, Version 1.4, ECP)
Scart Connector
—
Component Video Input shared with Composite
—
Digital Audio Output (Coax)
—
Digital Audio Output (Optical)
1 (back)
PC input(VGA) + PC Audio In
—
Headphone Output
1 (back)
General
Included Accessory*¹³
TV Remote (Bluetooth/embedded microphone)
Dimensions (W x H x D) (w/o stand)
1228 x 715 x 49
Dimensions (W x H x D) (with stand)*¹⁴
1228 x 749 x 251
Dimension Pedestal
560 x 9 x 251
Weight (w/o stand)
22.0 kg
Weight (with stand)
27.0 kg
VESA Compatible
Y
VESA Dimension
200x200 (M6)
Outer Boxed Unit (W x H x D)
1369 x 165 x 860
Total Boxed Weight
30 kg
